Sold
General Specifications
- X Axis Travel : 245 mm
- Z Axis Travel : 750 mm
- Swing Over Bed : 540 mm
- Distance between both the Centers : 750 mm
- Max Turning Diameter : 350 mm
- Max Turning length : 730 mm
- Spindle Speed : 35 to 3500 RPM
- Spindle Nose : JIS A2 8
- Max No of Tools : 12 Tools
- Shank Size : 25 mm
- Boring Bar Diameter : 40 & 50 mm
Product Info
- Mani Electric Motor Continuous 30 Min. Rating - AC 18.5 / 22 kW
- Total Power Consumption - 35.7kVA
- Floor Space Required (Width x Length) - 1920 mm x 2850 mm
- Overall Machine Height - 2040 mm
- App. Machine Weight - 5000 kg
- Equipped with jaws, Tool Shank, Base Plate and Manual Books.
