Available
General Specifications
- Max Swing : Diameter 440mm
- Max. Cutting Diameter : 254 mm
- Max. Cutting Length : 500 mm
- Max. Bar Work Size : 70 mm
- : -
- Spindle Speed : Max 3600 RPM
- Spindle Bore : Diameter 80 mm
- Spindle Nose : A2 - 8
- X Axis Travel : 180 mm
- Z Axis Travel : 510 mm
- Tailstock Diameter : 80 mm
- Stroke of Tailstock Sleeve : 130 mm
- Stroke of Tailstock Body : 430 mm
- Taper Type : MT # 4
- Electrical Power Supply : 34.6 kVA
Product Info
- Machine Equipped With:
- 1. Coolant Tank
- 2. Chip Conveyor
- 3. User Manuals
- 4. Base Levelling Pads
MACHINE DIMENSION
- 1. Bed Type - Flat
- 2. Floor Space (L X W) - 2765 X 1680 MM
- 3. Machie Height - 1712 mm
- 4. Machine Weight - 4,300 Kgs
